SC/APC Connector G652D 1310nm Fiber Optic Patch Cord

Name: SCAPC Connector G652D 1310nm Fiber Optic Patch Cord
Brand: SUNWISE
Price: 1 USD

China SC/APC Connector G652D 1310nm Fiber Optic Patch Cord wholesale

Brand Name : SUNWISE

Model Number : FSSCAPC

Certification : CE RoHS FCC,CE/TUV/ISO9001

Place of Origin : CHINA

Application : FTTH FTTB FTTX Network

Color : blue,blue or as required

Fiber type : G657A2,G652D,OS1,Singlemode or multimode

Connector type : SC; FC; LC; ST; MTRJ; MU; E2000; MPO; SMA; FDDI; DIN4; D4,Uniboot LC / APC / UPC

Product name : Armored Fiber Optic Patch Cable Cord,easy to strip fibre buffering sc/pc lc uniboot fiber patch cord

Insertion loss : ≤0.2 dB,PC/UPC/APC< 0.2dB

Return loss : UPC>55dB,>55dB,PC >45dB UPC >55dB APC >60dB

Wavelength : 1310nm/1550nm/850nm/1300nm

Material : LSZH,PVC

Connector : SC/LC/FC/ST

Operating temperature : -40 ~+75 Degree

Fiber counts : duplex,50/125um,simplex,4fibers to 144fibers

Cable type : indoor armored patch cord cable,drop cable

Fiber mode : SM/MM

Contact Now

waterproof Mini SC/APC optic connector Fiber Optic Patch Cord

APPLICATION

Fiber optic communications in harsh outdoor environments
 Outdoor communication equipment connection
 waterproof fiber equipment SC port
 Remote wireless base station
 FTTx wiring project

SC/APC Connector G652D 1310nm Fiber Optic Patch Cord

FEATUREScompact size, easy to operate, durable
 Easy connection to hardened adapters on terminals or closures
 Reduce welding, connect directly to achieve interconnection
 IP67 water and dust protection
 Spiral clamping mechanism ensures long-term reliable connection
 Guide mechanism, can be blinded with one hand, simple and quick, connect and install
 Seal design: It is waterproof, dust-proof, anti-corrosion and so on


   	 			Type
 			SM-UPC
 			SM-APC
 			MM-UPC

 			Typical
 			MAX
 			Typical
 			MAX
 			Typical
 			MAX

 			Insertion loss
 			≤0.1
 			≤0.3dB
 			≤0.15
 			≤0.3dB
 			≤0.05
 			≤0.3dB

 			Return loss
 			≥50dB
 			≥30dB
 			≥30dB

 			Durability
 			500 mating cycles

 			Working temperature
 			-40 to + 85℃



Product Tags:

G652D Fiber Optic Patch Cord

1310nm Fiber Optic Patch Cord

APC Connector Optical Patch Cord

SC/APC Connector G652D 1310nm Fiber Optic Patch Cord Images

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Sunwise Optical Communication Equipment Co.,Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Type	SM-UPC		SM-APC		MM-UPC
	Typical	MAX	Typical	MAX	Typical	MAX
Insertion loss	≤0.1	≤0.3dB	≤0.15	≤0.3dB	≤0.05	≤0.3dB
Return loss	≥50dB		≥30dB		≥30dB
Durability	500 mating cycles
Working temperature	-40 to + 85℃
